Siemens SIMATIC RF650R User Manual

Programming via XML interface
10.3 XML commands
SIMATIC RF650R/RF680R/RF685R
224 Configuration Manual, 03/2018, C79000-G8976-C386-06
Reply
<frame>
<reply>
<id> value_id </id>
<resultCode> 0 </resultCode>
<getBlacklist>
<returnValue>
<tagID> value_tagID </tagID> // opt
…
<tagID> value_tagID </tagID> // opt
</returnValue>
</getBlacklist>
</reply>
</frame>
// opt → Optional: Line can be omitted.
The error codes for negative replies ("resultCode" ≠ 0) are described in the section "Negative
XML replies (Page 263)".
Parameter
Parameter
Type
Values
Description
value_id Decimal value
0...9
0...4294967295 Unique command identifier
value_
sourceName
Text -- Read point name
The name is specified using the WBM
(refer to the section "The "Settings -
Read points" menu item (Page 54
)").
In the standard configuration, there is
only one read point with the name
"Readpoint_1".
value_tagID Hexadecimal
value
0...9, A...F
-- EPC-ID in "RAW Hex Data Format"
Example of a 96-bit EPC-ID:
3005FB63AC1F3681EC880468
For additional information, refer to the
"EPC Global Specification".
