Siemens SIMATIC RF650R User Manual

Programming via XML interface
10.3 XML commands
SIMATIC RF650R/RF680R/RF685R
240 Configuration Manual, 03/2018, C79000-G8976-C386-06
Parameter
Type
Values
Description
value_success Fixed values True
False
Flag to indicate whether or not the
command was successful for this tran-
sponder.
• True: Command successful
• False: Command unsuccessful
value_utcTime Time -- Optional
UTC time stamp (Universal Time Co-
ordinated) in ISO 8601 format:
yyyy-MM-ddTHH:mm:ss.fffzzz
e.g.: 2009-12-24T18:34:56.929+00:00.
value_
antennaName
Fixed values Antenna01
Antenna02
Antenna03
Antenna04
Optional
Name of the antenna
value_rSSI Decimal value
0...9
0..255 Optional
RSSI value
value_channel Decimal value
0...9
1...50 Optional
Channel number on which the tran-
sponder was detected.
value_power Decimal value
0...9
0, 5.00...33.00 Optional
Used radiated power of the antenna in
[dB]
Increment: 0.25 dB
value_polarization Fixed values Default
Circular
Linear_vertical
Linear_horizontal
All
Optional
Polarization of the antenna
Currently, this parameter can only be
set for the internal antenna of the
RF685R.
value_
commandRetry
Decimal value
0...9
0...65535 Optional
Number of times the reader repeated
commands attempting to obtain correct
data
"0" corresponds to no attempt.
The maximum number of attempts is
set using the WBM
value_airRetry Decimal value
0...9
0...65535 Optional
Number of times the reader repeated
air interface commands attempting to
obtain correct data
"0" corresponds to no attempt.
The maximum number of attempts is
specified in the reader firmware and
cannot be modified
