Siemens SIMATIC RF650R User Manual

Programming via XML interface
10.3 XML commands
SIMATIC RF650R/RF680R/RF685R
244 Configuration Manual, 03/2018, C79000-G8976-C386-06
Parameter
Type
Values
Description
value_bank -- 0...3 Memory bank of the transponder
• 0: Reserved
• 1: EPC
• 2: TID
• 3: USER MEMORY
value_
startAddress
Decimal value
0...9
0...65535 Start address of the first byte in the
memory bank where writing will start.
value_dataLength Decimal value
0...9
1...1024 Number of bytes to be written.
The reader checks the correct length of
"value_data".
If the check is negative, a negative
reply is sent.
value_password Hexadecimal
value
0...9, A...F
00000000...
FFFFFFFF
Optional
Access password for the transponder
This parameter does not need to be
defined if there is no password protec-
tion activated for the transponder.
value_data Hexadecimal
value
0...9, A...F
-- Data that should be written. Each byte
is represented by two hexadecimal
characters.
Example:
The byte sequence "0x12, 0x34, 0xA3"
is represented as the character string
"1234A3" in the "value_data" parame-
ter.
"value_dataLength" is 3 in this exam-
ple.
value_success Fixed values True
False
Flag to indicate whether or not the
command was successful for this tran-
sponder.
• True: Command successful
• False: Command unsuccessful
value_utcTime Time -- Optional
UTC time stamp (Universal Time Co-
ordinated) in ISO 8601 format:
yyyy-MM-ddTHH:mm:ss.fffzzz
e.g.: 2009-12-24T18:34:56.929+00:00.
value_
antennaName
Fixed values Antenna01
Antenna02
Antenna03
Antenna04
Optional
Name of the antenna
value_rSSI Decimal value
0...9
0...255 Optional
RSSI value
value_channel Decimal value
0...9
1...50 Optional
Channel number on which the tran-
sponder was detected.
