Siemens SIMATIC RF650R

Programming via XML interface
10.4 XML EventReports
SIMATIC RF650R/RF680R/RF685R
268 Configuration Manual, 03/2018, C79000-G8976-C386-06
Parameter
Parameter
Type
Values
Description
value_id Decimal value
0...9
0...4294967295 Unique command identifier
value_
sourceName
Text -- Read point name
The name is specified using the WBM
(refer to the section "The "Settings -
Read points" menu item (Page 54
)").
In the standard configuration, there is
only one read point with the name
"Readpoint_1".
value_tagID Hexadecimal
value
0...9, A...F
-- EPC-ID in "RAW Hex Data Format".
Example of a 96-bit EPC-ID:
3005FB63AC1F3681EC880468
For additional information, refer to the
"EPC Global Specification".
value_tagPC Hexadecimal
value
0...9, A...F
-- Optional
Tag PC (Protocol Control)
16-bit value represented by four hexa-
decimal characters.
Example:
The value "1234" corresponds to the
binary value "0001.0010.0011.0100".
value_event Fixed values New
Glimpsed
Observed
Lost
The transponder events are also gen-
erated by a smoothing algorithm in the
read point. The algorithms are speci-
fied in the WBM.
A report can also contain more than
one event for the same transponder.
Each individual event has its own tran-
sponder structure.
If a report contains two events for the
same transponder, two transponder
structures exist with the same "val-
ue_tagID" but different values for "val-
ue_event".
value_utcTime Time -- UTC time stamp (Universal Time Co-
ordinated) in ISO 8601 format:
yyyy-MM-ddTHH:mm:ss.fffzzz
e.g.: 2009-12-24T18:34:56.929+00:00.
value_
antennaName
Fixed values Antenna01
Antenna02
Antenna03
Antenna04
Name of the antenna
value_rSSI Decimal value
0...9
0...255 RSSI value
rSSIMin Decimal value
0...9
0...255 The lowest RSSI value with which the
transponder was detected. This is a
value without a unit and without direct
reference to the power strength.
