Programming via XML interface
10.4 XML EventReports
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
273
Reply
<frame>
<reply>
<id> value_id </id>
<resultCode> 0 </resultCode>
<ioer/>
</reply>
</frame>
The error codes for negative replies ("resultCode" ≠ 0) are described in the section "Negative
XML replies (Page 263)".
Parameter
Parameter
Type
Values
Description
value_id Decimal value
0...9
0...4294967295 Unique command identifier
value_ioName Fixed values Inport00
Inport01
Inport02
Inport03
Outport00
Outport01
Outport02
Outport03
Name of IO port
value_ioEvent Fixed values High
Low
Indicates the new status of the in-
put/output.
value_utcTime Time -- UTC time stamp (Universal Time Co-
ordinated) in ISO 8601 format:
yyyy-MM-ddTHH:mm:ss.fffzzz
e.g.: 2009-12-24T18:34:56.929+00:00.
