The following table provides an overview of all configurable reader parameters:
Table 5- 1 Configurable parameters of the reader
Parameter
Functionality
General
General settings of the reader
PROFINET interface [X1] All settings of the PROFINET interface
General
Name of the PN interface
Ethernet addresses
Setting of the IP address and device name
Advanced options Advanced PROFINET options such as update time, port settings,
belonging to an MRP domain etc.
Web Based Management Starting the WBM of the reader
Note: The WBM can only be started if either the PROFINET con-
nection between the CPU and reader is established or the reader
was assigned the IP address stored in the project. This means that
the device name has been assigned and the TIA configuration
must be loaded on the SIMATIC controller.
Module parameters
Enabling/disabling read point-related diagnostics messages.
Configuration management
• Loading configuration data on the reader from the STEP 7
project.
• Saving configuration data of the reader in the STEP 7 project.
RFID communication
Address parameters of the reader
General
General settings
I/O addresses I/O address parameter ("LADDR") of the reader. This parameter is
used in the "IID_HW_CONNECT" variable.
Digital inputs/outputs
Address parameters of the digital inputs/outputs of the reader.
General
General settings
I/O addresses I/O address parameter of the digital inputs/outputs.
Using the set address range (I/O address), the digital in-
puts/outputs configured in the WBM of the reader can be ac-
cessed.
