Configuring with the WBM
7.3 The menu items of the WBM
SIMATIC RF650R/RF680R/RF685R
58 Configuration Manual, 03/2018, C79000-G8976-C386-06
There are often simple explanations for these responses and therefore usually also
solutions. Algorithms are additional functions that help you to achieve the required
functionality even in difficult radio conditions. The following environmental conditions are
possible causes of this response:
● There are several readers in a restricted space, e.g. every 3 to 5 meters along a
production line (high reader density).
● The objects to be identified or the transponders are close together (the distance from
each other is less than the antenna field).
● There is a lot of metal in the environment (e.g. production environment with metallic
conveyor technology, loading doors with metal ramps)
● The objects to be identified are on a metal surface.
With the algorithms, you can optimize the write/read settings to ensure reliable
communication between reader and transponder. If none of these conditions applies, the use
of algorithms is usually unnecessary.
Note
Algorithms for trained users
Note that the following algorithms were designed specifically for trained users. Settings in
individual algorithms have effects on other algorithms. You should only work with the
algorithms when you are aware of the interdependencies between the various al
gorithms
In the section "Application examples of the algorithms (Page 319)" you will find several
examples of applications in which the use of the algorithms is described.
Click the "Adopt parameters from read point" button to transfer all parameters of the
algorithms and the session from another read point to this read point.
