Configuring with the WBM
7.3 The menu items of the WBM
SIMATIC RF650R/RF680R/RF685R
Configuration Manual, 03/2018, C79000-G8976-C386-06
75
Network ports
In the "Network ports" area, you can enable/disable the network ports of the readers. Click
on the check box of the required network port to enable or disable it.
Note
Disabling the network ports
Make sure that you do not disable the port via which you are currently communicating with
the reader.
Note
Requirement for port statistics
Using PROFINET diagnostics and via SNMP
you can create port statistics. Note that the
"Port statistics" function requires one
-port operation. Make sure that the network port which
is not in use is disabled with active port operating mode "With port statistics".
Enable the "LLDP" check box to activate the communications log. "LLDP" is a protocol for
checking the neighborhood.
SNMP
In the "SNMP" area, you can enable the network protocol. "SNMP" is a protocol for
monitoring network components.
When supplied from the factory this setting is disabled and it needs to be enabled here
before using SNMP for the first time.
Table 7- 15 Description of the SNMP properties
Property
Description
Community string
(reading)
Input box for specifying the user name for read access to SNMP varia-
bles.
Community string
(writing)
Input box for specifying the user name for write access to SNMP varia-
bles.
In this box, changes can only be made if write access was permitted.
Write access is only possible for the SNMP variables "sysName", "sys-
Location" and "sysContact" of the "system" group of MIB-2.
Allow write access Check box to enable/disable write protection for SNMP variables.
