CPU 1505SP (F) Ready4Linux Version 2.7
44 Operating Instructions, 05/2019, A5E46864285-AA
Commissioning in STEP 7
5
5.1 Insert CPU into configuration
Requirements
You have created a project in STEP 7.
You are in the device view.
Procedure
To create a configuration in STEP 7, follow these steps:
1. Open the hardware catalog.
2. Search for the CPU 1505SP in the hardware catalog.
3. Drag the article number of version V2.7 from the subfolder of the CPU to the device view.
The PC system is created and the CPU is inserted.
Result
The CPU is already preconfigured.
NOTICE
Hardware configuration
The following hardware configuration settings are predefined:
Index equals "1"
Storage location for retentive data on "NVRAM of the PC system".
Using Hardware LEDs with CPU 1505SP
Automatic startup after booting the PC
Do not change the predefined default values.
