Technical specifications
8.4 Technical specifications
SIMATIC IPC547G
154 Operating Instructions, 04/2020, A5E49948632-AA
Motherboard
Device with motherboard D3446
Device with motherboard D3445
Processor
• Intel
®
Pentium
®
Processor G4400
2C/2T, 3.3 GHz; 3 MB cache
• Intel
®
Core™ i5-6500
4C/4T, 3.2 (3.6) GHz; 6 MB cache;
iAMT
• Intel
®
Core™ i7-6700
4C/8T, 3.4 (4.0) GHz, 8 MB cache,
iAMT
• Intel
®
Xeon
®
Processor E3-1275 v5
4C/8T, 3.6 (4.0) GHz, 8 MB cache,
• Intel
®
Pentium
®
Processor G4400
2C/2T, 3.3 GHz; 3 MB cache
• Intel
®
Core™ i5-6500
4C/4T, 3.2 (3.6) GHz, 6 MB cache
• Intel
®
Core™ i7-6700
4C/8T, 3.4 (4.0) GHz, 8 MB cache
RAID (on-board) Intel
®
PCH with Intel
®
Rapid Storage
-
Slots for memory modules 4 x DIMM slots for DDR4 2133, expanda-
ble to 64 GB
2 x DIMM slots for DDR4 2133, expanda-
ble to 32 GB
Main memory 4 up to 64 GB, DDR4 SDRAM
4 up to 32 GB, DDR4 SDRAM
Max. of 3.2 GB can be used for 32-bit versions of operating system and applications;
see order documents for equipment
Expansion card slots * open direct plug sockets
• 2 × PCI
• 1 × PCIe x4* (4 lanes); Gen 3.0
• 1 × PCIe x4* (1 lane); Gen 3.0
• 1 × PCIe x16 (4 lanes); Gen 3.0
• 1 × PCIe x8* (1 lane); Gen 3.0
• 1 × PCIe x16; Gen 3.0
* open direct plug sockets
• 2 × PCI
• 2 × PCIe x4* (1 lane); Gen 2.0
• 1 × PCIe x16 (1 lane); Gen 2.0
• 1 × PCIe x8* (1 lane); Gen 2.0
• 1 × PCIe x16; Gen 3.0
Power consumption per PCI slot,
maximum permitted
• 5 V; 5 A or 3.3 V; 7 A
• 12 V; 0.5 A
• 12 V; 0.05 A
• 3.3 V
aux
; 0.4 A
Power consumption per PCIe slot
with x4 expansion card, maximum
permitted
• 3.3 V; 3 A
• 12 V; 2.1 A
• 3.3 V
aux
; 0.4 A
Power consumption per PCIe slot
with x16 expansion card, maximum
permitted
• 3.3 V; 3 A
• 12 V; 2.1 A
• 3.3 V
aux
; 0.4 A
Power consumption per slot, per-
≤ 25 W
Power loss all slots, permitted ≤ 80 W
In sum, the current for 3.3 V
aux
may not exceed 1.2 A.
