Technical specifications
8.4 Technical specifications
SIMATIC IPC547G
Operating Instructions, 04/2020, A5E49948632-AA
155
Graphics
Device with motherboard D3446
Device with motherboard D3445
Graphic controller
• Intel
®
HD Graphics 510
integrated in processor:
Intel
®
Pentium
®
Processor G4400
• Intel
®
HD Graphics 530
integrated in processor:
Intel
®
Core™ i5-6500
Intel
®
Core™ i7-6700
• Intel
®
HD Graphics P530
integrated in processor:
Intel
®
Xeon
®
Processor E3-1275 v5
• Intel
®
HD Graphics 510
integrated in processor:
Intel
®
Pentium
®
Processor G4400
• Intel
®
HD Graphics 530
integrated in processor:
Intel
®
Core™ i5-6500
Intel
®
Core™ i7-6700
Graphics memory Dynamic Video Memory Technology,
occupies 32 MB to 1.7 GB of main memory
Resolutions/frequencies/colors
• DVI up to 1920 × 1200 pixels at 60 Hz; color depth up to 32-bit/pixel
• DisplayPort up to 4096 × 2304 pixels at 60 Hz; color depth up to 32-bit/pixel
• VGA (VGA via DP-VGA adapter) up to 2560 × 1600 pixels at 60 Hz; color depth
up to 32-bit/pixel
Graphics card (optional) PCIe x16; Dual Head; 2 × DisplayPort
2
or 2 × VGA or 2 × DVI-D
1
• Type: NVIDIA NVS315, 1 GB graphics memory
• Maximum resolution:
– DisplayPort 2560 × 1600 at 60 Hz; 32-bit color depth
– DVI 1920 × 1200 at 60 Hz; 32-bit color depth
– VGA 2048 × 1536 at 60 Hz; 32-bit color depth
1
Adapter for VGA and DVI-D supplied
2
Available as spare part
Interfaces
Device with motherboard D3446
Device with motherboard D3445
COM 1 Serial interface 1 (V.24), 9-pin D-sub
socket
-
COM 2 (optional)
Serial interface 2 (V.24), 9-pole sub D socket
LPT (optional) Port for printer with parallel interface. The parallel interface supports the following
modes:
• STD Printer Mod
• SPP Mode
• EPP-1.9 and SPP Mode
• EPP-1.7 and SPP Mode
DisplayPort V1.2
1
2 x connection of a digital monitor
1 x connection of a digital monitor
