Siemens SIMOTICS S-1FL6 Compact Operating Instructions

Getting Started
106 A5E37208904-003, 04/2017
Read-only parameters
Par. No.
Name
Unit
Data type
r0020
Speed setpoint smoothed
rpm
Float
Description:
Displays the currently smoothed speed setpoint at the input of the speed controller or U/f charac-
teristic (after the interpolator).
Note:
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
The speed setpoint is available smoothed (r0020) and unsmoothed.
r0021
Actual speed smoothed
rpm
Float
Description: Displays the smoothed actual value of the motor speed.
Note:
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
The speed actual value is available smoothed (r0021) and unsmoothed.
r0026
DC link voltage smoothed
V
Float
Description: Displays the smoothed actual value of the DC link voltage.
Note:
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
The DC link voltage is available smoothed.
r0027
Absolute actual current smoothed
Arms
Float
Description: Displays the smoothed absolute actual current value.
Notice:
This smoothed signal is not suitable for diagnostics or evaluation of dynamic operations. In this case,
the unsmoothed value should be used.
Note:
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
The absolute current actual value is available smoothed (r0027) and unsmoothed.
r0029
Current actual value field-generating smoothed
Arms
Float
Description: Displays the smoothed field-generating actual current.
Note:
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
The field-generating current actual value is available smoothed (r0029) and unsmoothed.
r0030
Current actual value torque-generating smoothed
Arms
Float
Description: Displays the smoothed torque-generating actual current.
Note:
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
The torque-generating current actual value is available smoothed.
r0031
Actual torque smoothed
Nm
Float
Description: Displays the smoothed torque actual value.
Note:
Smoothing time constant = 100 ms
The signal is not suitable as a process quantity and may only be used as a display quantity.
The torque actual value is available smoothed (r0031) and unsmoothed.
r0034
Motor utilization thermal
%
Float
Description: Displays the motor utilization from motor temperature model 1 (I
2
t) or 3.
