Getting Started
A5E37208904-003, 04/2017
107
Description: Displays the temperatures in the power unit.
• [0]: Inverter maximum value
• [1]: Depletion layer maximum value
• [2]: Rectifier maximum value
• [3]: Air intake
• [4]: Interior of power unit
• [5]: Inverter 1
• [6]: Inverter 2
• [7]: Inverter 3
• [8]: Inverter 4
• [9]: Inverter 5
• [10]: Inverter 6
• [11]: Rectifier 1
• [12]: Rectifier 2
• [13]: Depletion layer 1
• [14]: Depletion layer 2
• [15]: Depletion layer 3
• [16]: Depletion layer 4
• [17]: Depletion layer 5
• [18]: Depletion layer 6
•
[19]: Cooling unit liquid intake
Dependency: Refer to A01009
Notice: Only for internal Siemens troubleshooting.
The value of -200 indicates that there is no measuring signal.
• r0037[0]: Maximum value of the inverter temperatures (r0037[5...10]).
• r0037[1]: Maximum value of the depletion layer temperatures (r0037[13...18]).
• r0037[2]: Maximum value of the rectifier temperatures (r0037[11...12]).
The maximum value is the temperature of the hottest inverter, depletion layer, or rectifier.
r0079[0...1
]
Torque setpoint total Nm Float
Displays and connector output for the torque setpoint at the output of the speed controller (before
clock cycle interpolation).
DC link voltage undervoltage threshold
Threshold to detect a DC link undervoltage.
If the DC link voltage falls below this threshold, the drive unit is tripped due to a DC link undervoltage condi-
Note: The value depends on the device type and the selected device rated voltage.
DC link voltage overvoltage threshold
If the DC link voltage exceeds the threshold specified here, the drive unit is tripped due to DC link
overvoltage.
Dependency: Refer to F30002.
Description: Displays the rated motor speed (rating plate).
