Siemens SIMOTICS S-1FL6 Compact Operating Instructions

Getting Started
A5E37208904-003, 04/2017
113
Par. No.
Name
Unit
Data type
r8931[0...3
]
PROFIdrive: Active IP address of station
-
U8
Description: Displays the active IP address for the onboard PROFINET interface on the Control Unit.
r8932[0...3
]
PROFIdrive: Active default gateway of station
-
U8
Description: Displays the active default gateway for the onboard PROFINET interface on the Control Unit.
r8933[0...3
]
PROFIdrive: Active subnet mask of station
-
U8
Description: Displays the active subnet mask for the onboard PROFINET interface on the Control Unit.
r8935
PROFIdrive: MAC address of station
-
U8
Description: Displays the MAC address for the onboard PROFINET interface on the Control Unit.
r8939
PROFIdrive: Device access point (DAP) ID
-
U32
Description:
Displays the PROFINET device access point ID for the onboard PROFINET interface.
The combination of device ID (r8909) and DAP ID uniquely identifies a PROFINET access point.
r29018[0...
1]
OA version
-
Float
Description: Displays the OA version.
Index:
• [0]: Firmware version
• [1]: Build increment number
r29400
Internal control signal status indicating
-
U32
Description:
Control signal status identifiers
The bits of the parameter are reseved except the following ones:
• Bit 1: RESET
• Bit 2: CWL
• Bit 3: CCWL
• Bit 10: TLIM
• Bit 19: SLIM
• Bit 23: REF
•
Bit 28: EMGS
r29942
DO signals status indicating
-
U32
Description:
Indicates the status of DO signals.
• Bit 0: RDY
• Bit 1: FAULT
• Bit 2: Reserved
• Bit 3: ZSP
• Bit 4: Reserved
• Bit 5: TLR
• Bit 6: Reserved
• Bit 7: MBR
• Bit 8: OLL
• Bit 9: Reserved
• Bit 10: Reserved
• Bit 11: Reserved
• Bit 12: Reserved
• Bit 13: RDY_ON
• Bit 14: STO_EP
