Siemens SIMOTICS S-1FL6 Compact Operating Instructions

Getting Started
36 A5E37208904-003, 04/2017
Type
1FL60...
42
44
61
62
64
66
67
90
92
94
96
Without
brake
LL
154.5 201.5 148 181/16
4.5
1)
181 214 247 189.5 211.5 237.5 289.5
KB1
93.5
140.5
85.5
118.5
118.5
151.5
184.5
140
162
188
240
KB2
-
-
-
With
brake
LL
201 248 202.5 235.5/
219
1)
235.5 268.5 301.5 255 281 307 359
KB1
140
187
140
173
173
206
239
206
232
258
310
KB2
31.5
39.5
44.5
With
straight
connect-
ors
KL1
136
158
184
KL2
92
115
149
KL3
13
23
34
KL4
14 22 34
With
angular
connect-
ors
KL1
96.2
117.5
143
KL2
84.6 108 141.1
KL3
13
23
34
KL4
14
22
34
•
①
−Power cable connector,
②
−Incremental encoder cable connector,
③
−Brake cable connector. These connectors
should be ordered separately. For more information about the order information of the connectors, see the SINAMICS
V90, SIMOTICS S-1FL6 Operating Instructions.
• The boundary dimensions of encoder connector−
② and brake connector−③ are the same.
•
The shaft height 90 mm motor has two M8 screw holes for eyebolts.
1)
The former value indicates the dimension for high inertia motors with straight connectors; the latter value indicates the
dimension for high inertia motors with angular connectors.
High inertia servo motor with straight connectors, with the absolute encoder
