Siemens SIMOTICS S-1FL6 Compact Operating Instructions

Getting Started
A5E37208904-003, 04/2017
37
High inertia servo motor with angular connectors, with the absolute encoder
Type
1FL60...
42
44
61
62
64
66
67
90
92
94
96
Shaft height
45
65
90
LC
90
130
180
LA
100
145
200
LZ
7
9
13.5
LB
80 - 0.03
110 - 0.035
114.3 - 0.035
LR
35
58
80
T
4 - 0.3
6 - 0.3
3 - 0.3
LG
10
12
18
D
19 - 0.013
22 - 0.013
35 - 0.016
DB
M6 x 16
M8 x 16
M12 x 25
E
30
50
75
QK
25
44
60
GA
21.5
25
38
F
6 - 0.03
8 - 0.036
10 - 0.036
Without
brake
LL
157 204 151 184/16
7.5
1)
184 217 250 197 223 249 301
KB1
100
147
92
125
125
158
191
135
161
187
239
KB2
- - -
With
brake
LL
203.5 250.5 205.5 238.5/
222
1)
238.5 271.5 304.5 263 289 315 367
KB1
147
194
147
180
180
213
246
201
227
253
305
KB2
31.5
39.5
44.5
With
straight
connect-
ors
KL1
136
158
184
KL2
60 60 60
With
angular
connect-
ors
KL1
96.2
117.5
143
KL2
60 60 60
