Parameters
10.2 Parameter list
SINAMICS V90, SIMOTICS S-1FL6
350 Operating Instructions, 04/2019, A5E36037884-007
Par. No.
Name
Min
Max
Factory
Setting
Unit
Data
type
Effective
Can be
changed
p1663 Current setpoint filter 2
denominator natural fre-
quency
0.5 16000.0 1000.0 Hz Float IM T, U
Description:
Sets the denominator natural frequency for current setpoint filter 2 (PT2, general filter).
Dependency: Current setpoint filter 2 is activated via p1656.1 and parameterized via p1663 ... p1666.
p1664 Current setpoint filter 2
denominator damping
0.001 10.000 0.300 - Float IM T, U
Description: Sets the denominator damping for current setpoint filter 2.
Dependency: Current setpoint filter 2 is activated via p1656.1 and parameterized via p1663 ... p1666.
p1665 Current setpoint filter 2
numerator natural fre-
quency
0.5 16000.0 1000.0 Hz Float IM T, U
Description: Sets the numerator natural frequency for current setpoint filter 2 (general filter).
Dependency: Current setpoint filter 2 is activated via p1656.1 and parameterized via p1662 ... p1666.
p1666 Current setpoint filter 2
numerator damping
0.000 10.000 0.010 - Float IM T, U
Description: Sets the numerator damping for current setpoint filter 2.
Dependency: Current setpoint filter 2 is activated via p1656.1 and parameterized via p1663 ... p1666.
p1668 Current setpoint filter 3
denominator natural fre-
quency
0.5 16000.0 1000.0 Hz Float IM T, U
Description: Sets the denominator natural frequency for current setpoint filter 3 (PT2, general filter).
Dependency:
Current setpoint filter 3 is activated via p1656.2 and parameterized via p1668 ... p1671.
p1669 Current setpoint filter 3
denominator damping
0.001 10.000 0.300 - Float IM T, U
Description:
Sets the denominator damping for current setpoint filter 3.
Dependency: Current setpoint filter 3 is activated via p1656.2 and parameterized via p1668 ... p1671.
p1670 Current setpoint filter 3
numerator natural fre-
quency
0.5 16000.0 1000.0 Hz Float IM T, U
Description: Sets the numerator natural frequency for current setpoint filter 3 (general filter).
Dependency: Current setpoint filter 3 is activated via p1656.2 and parameterized via p1668 ... p1671.
p1671 Current setpoint filter 3
numerator damping
0.000 10.000 0.010 - Float IM T, U
Description: Sets the numerator damping for current setpoint filter 3.
Dependency: Current setpoint filter 3 is activated via p1656.2 and parameterized via p1668 ... p1671.
p1673 Current setpoint filter 4
denominator natural fre-
quency
0.5 16000.0 1000.0 Hz Float IM T, U
Description: Sets the denominator natural frequency for current setpoint filter 4 (PT2, general filter).
Dependency: Current setpoint filter 4 is activated via p1656.3 and parameterized via p1673 ... p1675.
p1674 Current setpoint filter 4
denominator damping
0.001 10.000 0.300 - Float IM T, U
Description: Sets the denominator damping for current setpoint filter 4.
Dependency:
Current setpoint filter 4 is activated via p1656.3 and parameterized via p1673 ... p1675.
