Parameters
10.2 Parameter list
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2019, A5E36037884-007
373
Par. No.
Name
Min
Max
Factory
Setting
Unit
Data
type
Effective
Can be
changed
p29341 Warning 2 assigned for
digital output
1 6 2 - U16 IM T
Description:
Defines conditions for WARNING2.
• 1: Motor overload protection warning: 85% of overload threshold has been reached.
• 2: Holding brake power overload warning: threshold p29005 has been reached.
• 3: Fan warning: life time of fan expired (40000 hours), replacement of fan needed.
• 4: Encoder warning
• 5: Motor overtemperature warning: 85% of overtemperature threshold has been reached.
• 6: Capacitor service life warning: The capacitor has reached its expiry, so replace it.
p29350 Select sources for analog
output 1
0 12 0 - U16 IM T
Description:
Selects signal source for analog output 1.
• 0: Actual speed (reference p29060)
• 1: Actual torque (reference 3 × r0333)
• 2: Speed setpoint (reference p29060)
• 3: Torque setpoint (reference 3 × r0333)
• 4: DC bus voltage (reference 1000 V)
• 5: Pulse input frequency (reference 1k)
• 6: Pulse input frequency (reference 10k)
• 7: Pulse input frequency (reference 100k)
• 8: Pulse input frequency (reference 1000k)
• 9: Remaining number of pulses (reference 1k)
• 10: Remaining number of pulses (reference 10k)
• 11: Remaining number of pulses (reference 100k)
• 12: Remaining number of pulses (reference 1000k)
p29351 Select signal source for
analog 2
0 12 1 - U16 IM T
Description:
Selects signals for analog output 2.
• 0: Actual speed (reference p29060)
• 1: Actual torque (reference 3 × r0333)
• 2: Speed setpoint (reference p29060)
• 3: Torque setpoint (reference 3 × r0333)
• 4: DC bus voltage (reference 1000 V)
• 5: Pulse input frequency (reference 1k)
• 6: Pulse input frequency (reference 10k)
• 7: Pulse input frequency (reference 100k)
• 8: Pulse input frequency (reference 1000k)
• 9: Remaining number of pulses (reference 1k)
• 10: Remaining number of pulses (reference 10k)
• 11: Remaining number of pulses (reference 100k)
• 12: Remaining number of pulses (reference 1000k)
