General information
2.5 Accessories
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2019, A5E36037884-007
57
Filter used on the three phase power network
SINAMICS V90
Rated current
(A)
Tightening torque
(Nm)
Wire gauge (AWG)
Stripping length L
(mm)
200 V variant (6SL3210-5FB..-....)
10-1UA2 5 0.7 to 0.8 14 to 12 8
10-2UA2
10-4UA1
22 to 20
10-8UA0
18 to 16
11-0UA1
12 0.7 to 0.8
16 to 14
11-5UA0
14 to 12
12-0UA0
400 V variant (6SL3210-5FE..-....)
10-4UA0
5 0.7 to 0.8 15 to 13 8
10-8UA0
11-0UA0
11-5UA0
12 0.7 to 0.8 15 to 14
12-0UA0
13-5UA0
20 0.7 to 0.8 11 to 10
15-0UA0
17-0UA0
