General information
2.7 Technical data
SINAMICS V90, SIMOTICS S-1FL6
Operating Instructions, 04/2019, A5E36037884-007
79
Parameter
MOTION-CONNECT 300
Power Cable
MOTION-CONNECT 300
Encoder Cable
MOTION-CONNECT 300
Brake Cable
Outer diameter (mm)
• ø (7.8±0.3):
For high inertia motors of
0.4 kW to 1 kW
• ø (9.0±0.4):
For low inertia motors of
1.5 kW to 2 kW and high
inertia motors of 1.5 kW
to 7 kW
ø (6.9±0.3) ø (6.0±0.3)
Degree of protection (motor-
side only)
IP65
Bending cycles 1000000:
Maximum acceleration 3 m/s
2
, maximum speed 40 m/min
