Siemens SIMOTICS S-1FL6

Mounting
3.2 Mounting the motor
SINAMICS V90, SIMOTICS S-1FL6
90 Operating Instructions, 04/2019, A5E36037884-007
Shaft height 30 mm
Rated power
Rated torque
a
L
L1
LE
0.2 kW
0.64 Nm
39.5
98
132.5
27
0.4 kW
1.27 Nm
39.5
123
157.5
52
Shaft height 40 mm
Rated power
Rated torque
a
L
L1
LE
0.75 kW
2.39 Nm
48
139
178.3
40
1.0 kW
3.18 Nm
48
158.8
198.1
60
