SLE / SLE-DP – SIMOLINK Encoder 02.2001 Technical Data
Siemens AG GWE-477 763 4070.76 J
SIMOVERT MASTERDRIVES Operating Instructions 3-1
3 Technical Data
Product name SLE-DP SLE
Order number 6SX7005-0AG01 6SX7005-0AG00
Size [mm]:
– Width
– Height
– Depth
Dimensions (housing)
52 (52)
118 (107)
88 (80)
Dimensions (housing)
35 (35)
118 (107)
88 (80)
Weight Approx. 400 g Approx. 300 g
Degree of protection IP20 to EN 60529
Degree of pollution
Not applicable
Moisture condensation is not permissible in operation
Mechanical strength:
– In steady-state operation
– During transportation
Not applicable
Climate class Class 3K3 to DIN IEC 721-3-3 (in operation)
Cooling method (operation) Convection
Permissible ambient or
coolant temperature:
– In operation
– In storage
– During transportation
0 °C to +55 °C
–25 °C to +70 °C
–25 °C to +70 °C
Permissible humidity rating:
– Transport/storage
– In operation
Relative air humidity
≤ 95 %
≤ 85 % (condensation not permitted)
Power supply
Rated supply voltage DC +24 V (+21 V to +28 V)
Power consumption Approx. 200 mA Approx. 130 mA
Encoder interface
Track A, track B, zero track RS422 to EIA422 standard
Supply voltage:
– Electrical isolation
Internal
Isolating voltage 500 V DC to 24 V voltage supply
Isolating voltage 500 V DC
to PROFIBUS interface
Fiber-optic cable connection
Transmitter power Fixed (maximum transmitter power defined for SIMOLINK)
Fiber-optic cable modules
– Transmitter
– Receiver
Hewlett Packard:
HFBR 1528
HFBR 2528
PROFIBUS interface
Supply voltage:
– Electrical isolation
Internal
Isolating voltage 500 V DC to
24 V voltage supply and
encoder interface
Output voltage
DC + 5 V, max. 100 mA
– for bus connection or
– supply of an OLP
Data transfer rate Max. 12 Mbaud
Table 3-1 Technical data
