SLE / SLE-DP – SIMOLINK Encoder 02.2001 Installation
Siemens AG GWE-477 763 4070.76 J
SIMOVERT MASTERDRIVES Operating Instructions 4-1
4 Installation
The SIMOLINK Encoder module is snapped onto an EN 50022-
compliant TS 35 top-hat rail. The requisite mechanical mounting
elements are fitted in the housing.
4.1 EMC measures
The module is connected to ground via the top-hat rail. The ground
connection between the rail and the equipotential bonding conductor
must be made by the end-user during installation.
For further information, please refer to Chapter "Instructions for Design
of Drives in Conformance with EMC Regulations" of the SIMOVERT
MASTERDRIVES Compendium Motion Control, Order No.:
6SE7087-6QX50.
