Start-Up 02.2001 SLE / SLE-DP – SIMOLINK Encoder
GWE-477 763 4070.76 J Siemens AG
6-14 Operating Instructions SIMOVERT MASTERDRIVES
6.4.3 Device master file (GSD file)
The SLE-DP is defined in a PROFIBUS environment via its Ident
number and the associated device master file (GSD file, Appendix C).
Ident No.: 0x80A9
File: SIEM80A9.GSD
Version: V1.0 dated March 23, 2000 (Appendix B)
To be able to operate the SLE-DP in conjunction with a SIMATIC within
a PROFIBUS network, this GSD file must be copied into ’HW Config’ of
the SIMATIC Manager. To do this, proceed as follows:
1. Start the SIMATIC Manager
2. Call HW Config
3. Select the ’Tools’ menu and
4. Execute menu command ’Install new GSD’ and integrate file
’SIEM80A9.GSD’.
The SLE-DP can then be found as a ’PROFIBUS Object’ for connection
configuring in ’NETPRO’ under: ’Network Objects / PROFIBUS-DP /
Other Field Devices / General’.
6.4.4 Sample program for SLE-DP with S7-300
After the GSD file has been installed (HW Config) and the PROFIBUS
connection configured (NETPRO), the SLE-DP can be addressed with
simple load or transfer commands provided that its PROFIBUS-DP
station address has been set (NETPRO Fig. 6-7 and HW Config) and
the input and output addresses assigned (HW Config Fig. 6-8).
Input and output data words must be processed as 2-byte consistent
data words.
NOTICE
