6.1.3 Bottom DIL switch S3
The node address of the SIMOLINK Encoder is set via DIL switch S3.
Switch Designation Meaning Range
S3.1 2
0
S3.2 2
1
S3.3 2
2
S3.4 2
3
S3.5 2
4
S3.6 2
5
S3.7 2
6
S3.8 2
7
SIMOLINK Encoder node address
Note:
S3.1 is the least significant bit
1…200
Table 6-4 Meaning of DIL switch S3
The SIMOLINK Encoder returns its internal pulse counter actual value
plus a status bit "STATUS-SLE" via SIMOLINK. It writes this to its
actual-value telegram that is defined by the send address
(= node address) and channel address (= 0, fixed setting).
If the SIMOLINK Encoder is activated even though the node address is
incorrectly set (i.e. 0 or >200), then ’1’ is transferred as the node
address, i.e. the SIMOLINK Encoder writes to the telegram of the node
with address ’1’.
