10.04 Alarms and Messages
8.2
A
larms in Sho
p
Mill
8
 Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operation/Programming ShopMill (BAS) – 10.04 Edition 8-411
112420
Error on inch/metric changeover! Check all data!
Explanation Data conversion not completed for inch/metric changeover.
Response Alarm display
NC Start disable
Remedy Check the following data:
• Display machine data:
MD9655: $MM_CMM_CYC_PECKING_DIST
MD9656: $MM_CMM_CYC_DRILL_RELEASE_DIST
MD9658: $MM_CMM_CYC_MIN_COUNT_PO_TO_RAD
MD9664: $MM_CMM_MAX_INP_FEED_P_MIN
MD9665: $MM_CMM_MAX_INP_FEED_P_ROT
MD9666: $MM_CMM_MAX_INP_FEED_P_TOOTH
MD9670: $MM_CMM_START_RAD_CONTOUR_POCKET
MD9752: $MM_CMM_MEASURING_DISTANCE
MD9753: $MM_CMM_MEAS_DIST_MAN
MD9754: $MM_CMM_MEAS_DIST_TOOL_LENGTH
MD9755: $MM_CMM_MEAS_DIST_TOOL_RADIUS
MD9756: $MM_CMM_MEASURING_FEED
MD9757: $MM_CMM_FEED_WITH_COLL_CTRL
MD9758: $MM_CMM_POS_FEED_WITH_COLL_CTRL
MD9759: $MM_CMM_MAX_CIRC_SPEED_ROT_SP
MD9761: $MM_CMM_MIN_FEED_ROT_SP
MD9762: $MM_CMM_MEAS_TOL_ROT_SP
MD9765: $MM_CMM_T_PROBE_DIAM_LENGTH_MEAS
MD9766: $MM_CMM_T_PROBE_DIAM_RAD_MEAS
MD9767: $MM_CMM_T_PROBE_DIST_RAD_MEAS
MD10240: $MN_SCALING_SYSTEM_IS_METRIC
MD20150 [12]: $MC_GCODE_RESET_VALUES
• Tool data for various edges D:
Length Z, radius R,
wear lengths Z and R
• Work offsets:
Base offset
Position in X, Y, Z and A, C (if available)
Work offset
• Settings in MANUAL operating mode:
Retraction plane
Safety clearance
Note This alarm is only output on a hardware fault.
112500
Error in the NC interpreter % module %1
Explanation The ShopMill program cannot be opened.
Response Alarm displayed
interpreter stopped
Remedy Please note the error text and contact the Siemens A&D MC Hotline.
