4
Machine Operating Area 03.04
4.6 Automatic mode
4
Ó Siemens AG, 2004. All rights reserved
4-154 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Programs
MAIN1.MPF
1 G90
2 X100 Y200 F2000
3 EXTCALL "SUBPRG1"
4 X200 Y400
5 EXTCALL "SUBPRG2"
6 EXTCALL "SUBPRG3"
7 X0 Y0
Search target 1 8 EXTCALL "SUBPRG2"
9 X50
10 M30
SUBPRG2.SPF
1 X200 Y300
2 X400 Y500
3 EXTCALL "SUBPRG3"
.
.
Search target 2 4000 EXTCALL "SUBPRG3"
.
.
5000 M17
SUBPRG3.SPF
1 X20 Y50
2 .
.
Search target 3 2300 X100 Y450
.
.
5000 M17
A distinction is made between the following two cases for block
search:
1. The main program MAIN1.MPF is in the NC, the subroutines
SUBPRG1.SPF to SUBPRG3.SPF are processed externally.
2. The main program MAIN1.MPF and the subroutines
SUBPRG1.SPF to SUBPRG3.SPF are processed externally.
Case 1
· Search target 1: The NC does not consider the EXTCALL calls in
lines 3, 5, and 6 of the main program MAIN1.MPF and jumps to
the search target Line 8.
· Search target 2: The NC jumps to the search target at line 4000 of
external subroutine SUBPRG2.SPF; the previous statements in
the external program are skipped.
· Search target 3: The NC jumps to the search target at line 2300 of
external subroutine SUBPRG3.SPF; the previous statements are
skipped, and the search stops.
On NC Start, the subroutine SUBPRG3.SPF is processed starting at
the destination line.
