"Parameters" Operating Area 03.04
5.1 Tool data
5
Ó Siemens AG, 2004. All rights reserved
5-180 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Tool type 4xy (grinding tools) is calculated separately.
For the geometric values (e.g. length or radius), there are several
entry components.
Parameters Grinding wheel-
comp. left
Grinding wheel
-
comp. right
Dresser
left
Dresser
right
Tool-specific parameters
$TC_DP1 Tool type
*(2
0
=1)
Tool type Tool type
$TC_DP2 Tool point
direction
Tool point
direction
Tool point
direction
Tool point
direction
Geometry tool length compensation
$TC_DP3 Length 1
*(2
2
=4)
Length 1 Length 1
$TC_DP4 Length 2
*(2
3
=8)
Length 2 Length 2
$TC_DP5 Length 3
*(2
4
=16)
Length 3 Length 3
$TC_DP6 Radius Radius Radius Radius
$TC_DP7 to
$TC_DP11
Reserved Reserved Reserved Reserved
Wear tool length compensation
$TC_DP12 Length 1
*(2
11
=2048)
Length 1 Length 1
$TC_DP13 Length 2
*(2
12
=4096)
Length 2 Length 2
$TC_DP14 Length 3
*(2
13
=8192)
Length 3 Length 3
$TC_DP15 Radius Radius Radius Radius
$TC_DP16 to
$TC_DP20
Reserved Reserved Reserved Reserved
Base dimension/adapter dimension tool length compensation
$TC_DP21 Basic length 1
*(2
20
=1048576)
Basic length 1 Basic length 1
$TC_DP22 Basic length 2
*(2
21
=2097152)
Basic length 2 Basic length 2
$TC_DP23 Basic length 3
*(2
22
=4194304)
Basic length 3 Basic length 3
