5
"Parameters" Operating Area 03.04
5.3 Tool mana
ement
5
Ó Siemens AG, 2004. All rights reserved
5-198 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Buffer
locations
Display and skip the buffer window in the magazine list. The display
shows spindles, grippers, etc., i.e. locations which can accommodate
tools but which are not magazine locations. If no intermediate memory
is defined, this key has no function.
Search and
position
The "Find tool/location" window appears.
· Search
- Tool:
Enter the tool name and Duplo number and start the search
with OK.
The cursor is positioned on the tool found.
- Location:
Enter the magazine and location number and start the search
with OK.
The cursor is positioned on the tool found.
· Positioning
Select softkey "Position", tool/location is moved to loading point. If
there is more than one possible loading point, a window is opened.
You can select the correct one with the cursor.
Next
magazine
The locations of the next magazine are displayed in the magazine list.
You can only scroll forwards. When you reach the last magazine, the
display returns to the first magazine.
(Names assigned by
user)
Vertical softkeys (tool list)
Selection of a table structure configured by the user
(if configured), e.g.:
Tool
list 1
· General data
Tool
list 2
· Geometry tool data
Tool
list 3
· Wear data
Tool
details
You can display and edit the complete data of a tool (as in the
magazine list).
Tool from
CC
The tool data are read from a code carrier and entered in the tool list
(you can then edit the data).
