5
03.04 "Parameters" Operating Area
5.3 Tool mana
ement
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-199
Tool in
cabinet
Select the tool in the tool cabinet.
The tool data are read from there and entered in the tool list.
A list display appears for which you can parameterize a filter for the
tool number, duplo number and tool type. The list displays all the tools
that fulfill the filter criteria. You can select the tool you require from the
list.
Delete
tool
The selected tool is removed from the list. Use the vertical softkeys to
determine whether to save the tool data.
Tool in
cabinet
The data are copied into the tool cabinet. The tool can be loaded later
with the same data.
Data on
CC
If a code carrier is installed, the tool data are stored on the carrier.
The tool can then be loaded later with the same data.
bort
The operation is canceled. The tool is not removed from the list.
OK
The tool is deleted from the list. The tool data are no longer available.
New tool
Each time you press this softkey, a tool is created immediately. The
screen form for entering the tool data (tool details) and the associated
softkey bar (same as tool details) appear. The values are initialized
with the default settings (configured in the INI file) and can be
modified here (e.g. you can change the name of the tool).
Use the vertical softkey bar to display the tables for cutting edge data
and offsets with the default settings. If necessary, enter any changes
in the individual views.
<<
Terminates input of the tool data and switches to the tool list display.
The new tool appears in the table and is available for loading.
Once you have set up a new tool, the cursor automatically jumps to
the line containing the new tool when you return to the tool list. This
gives you feedback about your operation.
