5
03.04 "Parameters" Operating Area
5.3 Tool mana
g
ement
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-209
Other information
For information on NC variables, please refer to the Description of
Functions
/FB/, W4 Grinding-Specific Tool Offset and Monitoring.
Bottom section:
Tool OEM data are displayed as in the basic display for tool details.
The tool OEM data can be modified in both the grinding data display
and the basic display for tool details. The designation and the unit in
the OEM data can be parameterized in the relevant language. The
bottom section of the display is only available if tool OEM data are
available on the NC.
Scrollbar A scroll bar appears next to the middle and bottom sections if the
bottom section is displayed.
The grinding data display and the softkeys are only displayed if the
tool is a grinding tool (tool type between 400 and 499).
Access rights are checked for grinding data.
Default access is "All".
All cutting edges on a tool are of the same type. The same applies to
the dresser cutting edges of grinding tools.
Tool types The tool types for grinders are 4xy in accordance with /FB/, W4.
They are available in displays/functions for:
· Tool cabinet
· Tool catalog
· Cutting edge parameters in tool details
· Lists (magazine list, tool list, working offset list)
Boundary conditions - The tool-specific grinding data cannot be displayed in the
list displays.
- They are not saved in the tool cabinet/tool catalog.
- They are not transferred via code carrier/SINCOM.
- The extension is available in HMI Advanced Version 6.2
or later.
