8
03.04 "Diagnosis" Operating Area
8.3 Service dis
la
8
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 8-413
Active stop
Currently requested external stop
Stop F code value (alarm 300911)
Pulse enabled
Traversing disable via stop in other axis
Operating sequence
Service
displays
Select the menu headed "Service displays".
The horizontal softkey bars change.
Service
SI
The "Service SI" window displays information about Safety Integrated
data together with the associated axis name and axis number.
You can page up and down with the "Page" keys.
Axis
+
Axis
-
The service values of the next (+) and the previous (-) axis are
displayed.
Direct
selection...
An axis can be directly selected from the available axes.
SGE/SGA
Use this softkey to display the safety-relevant input and output signals
SGE and SGA.
SPL
Use this softkey to display the s
afe programmable logic signals SPL.
