Siemens SINUMERIK 810D User Manual

8
03.04 "Diagnosis" Operating Area
8.3 Service dis
p
la
y
8
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 8-415
Saving
Your variable sections and assigned bit ranges are saved and are
included when the screen is activated subsequently.
In addition to the current values, the origin of the displayed NCK/PLC
signals is displayed.
Format
Pre-assigned format...
The following formats can be selected in the variable rows using the
select key B Binary
H Hexadecimal
D Decimal.
The same formats can be selected in the submenu using the softkey
"Pre-assigned format...". The selected format is applied to all variable
displays in the screen.
Individually set or fixed format settings are saved and taken into
consideration in the following displays.
Selectable variables $A_INSE(P)
$A_OUTSE(P)
$A_INSI(P)
$A_OUTSI(P)
$A_MARKERSI(P)
Displayed signals KDV level (KDV = cross-checking)
Cross-checking status
Cross-checking control word
SPL power up status
SPL powered up
SPL interfaces are parameterized
"SAFE.SPL" SPL program file loaded
NCK waits until the PLC has started
Interrupt for SPL start should be assigned
Interrupt for SPL start has been assigned
Interrupt processing for SPL start called
Interrupt processing for SPL start terminated
NCK cross-checking has been started
PLC cross-checking has been started
Cyclic SPL checksum test active
All SPL protection features active
