9
03.04 "Startup" Operating Area
9.1 Machine data
9
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 9-439
Protection level Locked by Range
0 Password Siemens
1 Password Machine manufacturer
2 Password Installation engineer, service
3 Password End user
4 Keyswitch position 3 Programmer, machine setter
5 Keyswitch position 2 Qualified operator
6 Keyswitch position 1 Trained operator
7 Keyswitch position 0 Semi-skilled operator
Depending on the authorization level, it will be possible to edit data
such as cycles and machine data.
Access levels 0 to 3 require the input of a password. The password
for level 0 provides access to all data areas. At system boot in Startup
mode (NCK startup switch in position 1), the default passwords are
entered as standard.
Press softkey "Password" to set default passwords 1 to 3 which were
entered at system boot after activation to the required standard for the
software version.
If one of the above passwords is set, the keyswitch position is
ignored.
For further information, please see
/IAD/, Installation and Start-Up Guide, "Parameterization of the
control".
/IAM/, IM4 Start-up HMI Advanced, "Function/Parameters"
Operating sequence
Start-up
The operating area The operating area "Start-up" is selected.
Password...
Press softkey "Password.
You can activate the password for the system via the horizontal
softkeys Set password, Delete password and Change password.
Set
password
Press softkey "Set password".
The input window for entering the password is displayed.
Enter one of the three possible default passwords and press the Input
key or symbol to confirm. A permissible password is acknowledged as
set and the currently applicable access level is displayed. Invalid
passwords will be rejected. You must delete the old password before
activating a password for a lower access level than the one activated.
