9
03.04 "Startup" Operating Area
9.6 HMI
9
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 9-455
Templates
When creating a new workpiece, specify here whether templates for:
· Job lists
· Part programs or
· Initialization programs
are to be transferred to the new workpiece (directory).
For more information, see Subsection 6.1.5 Templates
Action
log
When you press the softkey, a screen is opened for setting
parameters and activating the action log. You can make and save the
following settings:
· Logging on
· Alarm status change;
· Keys (ShopMill only)
· Channel status/override;
· Data writing
· File access
· Instructions (PI services program invocation)
Input fields are available for:
Write interval
Log file size
Logged alarms
Trace
In the event of communications errors, a trace log for communications
processes can be recorded following an instruction to the Service
department or to our hotline. The trace log is evaluated by the
Siemens HMI Development department.
Operating sequence
Start-up
The operating area "Start-up" is selected.
MMC
Select softkey "MMC".
The horizontal and vertical softkey bars change.
System
settings
Next select one of the desired functions:
Horizontal softkeys:
File
display
The "Settings for file display" window is opened.
Inquiry
The "Settings for inquiries" window is opened.
You can specify whether or not an inquiry window should be displayed
after certain commands, e.g. Delete.
