9
"Startup" Operating Area 03.04
9.6 HMI
9
Ó Siemens AG, 2004. All rights reserved
9-456 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Symbols
The "Representation of keys in displays..." window is opened.
Templates
Use workpiece templates
For more information, see Subsection 6.1.5 Templates
Action
log
Log control processes
Vertical softkey:
Sort...
Sort the information into order according to a sorting criterion or
sequence
A dialog box is displayed for setting the sorting sequence of one
column.
The defined sequence applies for the display of the corresponding
window in the operating areas: machine, program, services of the
selected column.
You can select a sorting criterion:
· No sorting (by default the information is sorted in ascending order
by column name) or
· One of the column designations
You can also select the sorting sequence:
· Descending or
· Ascending
Confirm with OK.
In the operating areas
The sorting sequence set is shown as an arrow symbol next to the
column name of the column selected as the sorting criterion.
In HMI Advanced systems with an optional mouse, the following
operating options are also available for column sorting:
1. A click on the column name with the arrow symbol changes the
direction and sorts the information accordingly.
2. A click on another column makes this the sorting criterion.
With another click the direction can be changed, if necessary, as
in (1.)
The selection of another sorting criterion in the operating area
changes the sorting criterion for all operating areas (machine,
program, services).
Other information
When the sorting sequence is set using the softkey "Sort", if the
sorting criterion is not available in the display image of the operating
area, the information is sorted in ascending order according to the
column name. The sorting sequence defined in the dialog box applies
to the operating areas, in which the criterion set in the dialog box
appears.
