03.04 Operator Components/Sequence of Operations
2.5 Screen la
y
out
2
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 2-49
3 Channel operational
messages
From
SW 6.2: For displaying the channel operational messages with
symbols, see Subsection 4.1.2.
If the status shows this symbol
, operating input is required.
1 Stop: No NC ready
2 Stop: Mode group ready
3 Stop: Emergency Stop active
4 Stop: Alarm active with stop
5 Stop: M0/M1 active
6 Stop: Block ended in SBL mode
7 Stop: Cycle Stop active
8 Wait: Read-in enable missing
9 Wait: Feedrate enable missing
12 Wait: Axis enable missing
17 Wait: Feed override > 0%
18 Stop: Error in NC block
19 Wait: For NC blocks from external
22 Wait: No spindle enable
23 Wait: Axis feedrate value is 0
31 Stop: No channel ready
45 Stop: SERUPRO found the search item and the NCK
stopped. SERUPRO is the abbreviation for
SEarchRUn by PROgram testing,
which is a new type of search mode.
If the status shows this symbol
operation is generally not required.
10 Wait: Dwell active
11 Wait: Aux. funct. ackn. missing
13 Wait: Exact stop not reached
14 Wait: For positioning axis
15 Wait: For spindle
16 Wait: For other channel
20 Wait: Due to SYNACT instruction
21 Wait: Block search active
24 Wait: For tool change acknowledgement
25 Wait: For gear stage change
26 Wait: For position control
27 Wait: For thread cut
