Operator Components/Sequence of Operations 03.04
2.5 Screen la
y
out
2
Ó Siemens AG, 2004. All rights reserved
2-50 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
29 Wait: For punching
30 Wait: For safe operation
32 Stop: Oscillation active
33 Stop: Axis replacement active (block change inhibited by
initiation of an axis replacement)
34 Wait: For axis container rotation
35 Wait: AXCT axis active as slave axis
36 Wait: AXCT axis active as master axis
37 Wait: AXCT axis changing to follow-up
38 Wait: AXCT internal status change in axis
39 Wait: AXCT axis drive disable
40 Wait: AXCT axis overlaid motion active
41 Wait: AXCT axis axis replacement active
42 Wait: AXCT axis interpolator active
43 Wait: WAIT_FOR_CC_ENABLE: Waiting for compile cycle
44 Wait: On access to system variable
46 Stop: ESR triggered
47 Wait: Axis container rotation waiting for spindle stop
48 Wait: Axis container rotation waiting for MD data match
(New-Config)
49 Wait: For axis replacement: Axis currently coupled
50 Wait: For axis replacement: Liftfast active
51 Wait: For axis replacement: New-Config active
52 Wait: For axis replacement: Axis container rotation active
53 Wait: For axis replacement: Waitp active
54 Wait: For axis replacement: Axis is currently in another
channel
55 Wait: For axis replacement: Axis is currently PLC axis
56 Wait: For axis replacement: Axis is currently reciprocating
axis
57 Wait: For axis replacement: Axis is currently jog axis
58 Wait: For axis replacement: Axis is currently command
axis
59 Wait: For axis replacement: Axis is currently OEM axis
60 Wait: For axis replacement: Axis is currently following axis
coupled to master value
61 Wait: For axis replacement: Axis is currently coupled-
motion axis
62 Wait: For axis replacement: Axis is currently coupled slave
axis
