03.04 Operator Components/Sequence of Operations
2.5 Screen la
y
out
2
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 2-51
4 Channel name Name of the channel in which the program is running.
5 Alarm and message line - Alarms and messages or
- Information that was programmed in the part program
using the MSG command (if no alarms pending)
6 Operating mode display The currently selected mode JOG, MDI or Auto (Automatic) is
displayed.
From software Version 6.2:
The active submode is displayed next to the operating mode. An
active increment is also displayed below. For example:
JOG Repos
1000
7 Program name Press NC Start to execute this program.
From software Version 6.2:
The "Program name" output field can be configured for JOG and MDI.
See machine manufacturer's specifications.
8 Program status The current status of the part program being executed is output
- Program aborted
- Program running
- Program stopped
From software Version 6.2:
The "program status" output field can be configured, e.g. with the
"Channel-wide status display with symbols" function
(Subsection 4.1.3); see machine manufacturer's specifications.
9 Program control display Functions that have been activated are visible can be set via
"Program control", see Section 4.6 Automatic mode, "Program
control"
