Siemens SINUMERIK 810D User Manual

2
Operator Components/Sequence of Operations 03.04
2.6 General se
q
uence of o
p
eration
2
Ó Siemens AG, 2004. All rights reserved
2-62 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Abort
If you abort Find + Replace, the process is stopped and the window
closed. You are back in "Edit mode" again".
Save
file
Save file
Changes are saved in the file loaded in the editor.
Other Information
Please note that the changes to programs stored in the NC memory
take immediate effect.
The save options for the control system can be altered in the
"Settings" menu (e.g. save automatically, etc.).
(See "Start-up" section)
Close
editor
Close editor
When you select softkey "Close editor", a dialog box may appear in
which you must confirm whether or not to save the changes. The text
editor is then closed and the current program overview is displayed
again.
Horizontal softkeys
Free contour programming
Contour
Generate
contour
Use the "Contour" and "Generate contour" softkeys to call up the free
contour programming function.
Accept
contour
The part program block is inserted in the part program with the
appropriate parameters.
Setting parameters for cycles
The following functions are provided as programming support:
· Drilling, milling, turning (cycles)
· Contour (free contour programming)
Drilling Milling
Turning
You can call up the relevant cycle compilation via the vertical softkeys
Drilling, Milling, Turning.
Enter the new values for the cycle parameters.
OK
The part program block is inserted in the part program with the
appropriate parameters.
Example:
CYCLE81 (110, 100, 2, 35)
/PGC/, Programming Guide Cycles
