2
03.04 Operator Components/Sequence of Operations
2.6 General se
q
uence of o
p
eration
2
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 2-63
Simulation
Simulation
The simulation is called (see /BA/, Operator's Guide, Interactive
Programming or Chapter 6 Program Operating Area).
Softkey "Simulation" is displayed only if the simulation function can be
called in the current operating situation.
Recompile
If program steps (cycle/contour) have already been parameterized but
must be changed, you can display and edit the parameter values with
their meanings.
Position the cursor in the text editor on the line with the program step
(contour/cycle) whose parameters you wish to change.
Recompile
A screen form containing the parameter settings for the selected
cycle/contour appears on the screen.
Change the parameters.
OK
The part program block is automatically inserted in the part program
with the new parameters.
Renumber
The block numbering in the program shown in the editor is executed
again according to the values defined under the "Settings" softkey.
Settings
Settings
Define the following values in the window "Editor Settings":
· Horizontal scrolling ON/OFF
· Display hidden lines ON/OFF
· Deactivate LF in program
If this setting is selected, a space is displayed in the editor window
on the monitor in place of the linefeed character. In the file to be
edited, the linefeed character is retained.
· Time interval for Automatic Save
When you set Automatic Save, you can also set the time intervals
at which text must be saved automatically (applicable only to files
on hard disk). If a value ¹ 0 is entered, the softkey "Save file" is not
displayed. If the value 0 is entered, automatic save is not
performed.
· Automatic numbering ON/OFF
A new block number is automatically inserted on every new line. If
you wish to assign new block numbers to an existing program, use
the "Renumber" function.
· Number of first block
· Incrementation of block numbers (e.g. 1, 2, 10)
