2
Operator Components/Sequence of Operations 03.04
2.6 General se
uence of o
eration
2
Ó Siemens AG, 2004. All rights reserved
2-64 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Setting
contour
The following settings are possible for contour programming:
· Last line
Each time you complete a program step in the contour
programming you can insert a text in the last line
(e.g. "End of contour").
Other information
· The coordinate system and the technology to be used are set via
the machine data; see /IAM/ Installation and Start-Up Guide IM4.
· Edited programs are automatically enabled after saving.
