2
Operator Components/Sequence of Operations 03.04
2.6 General se
uence of o
eration
2
Ó Siemens AG, 2004. All rights reserved
2-68 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Other information
· Horizontal softkeys are assigned to vertical softkeys in the
NETNAMES.INI file. The assignment merely represents an HMI-
specific grouping characteristic.
· When you select a vertical softkey, you are selecting a channel
and potentially an NC as well.
· Channels that are configured in the channel menu, but defined as
a channel gap in the corresponding NC, will not be displayed.
· If an application (e.g. processing from external source) disables
switchover to the selected NC, then only the channels of the
current NC are displayed in the channel menu.
