Siemens SINUMERIK 840D Operator's Guide

4
Machine Operating Area 03.04
4.1 Data structure of the NC control
4
Ó Siemens AG, 2004. All rights reserved
4-100 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Operating sequence
Selection of mode
The selected mode is displayed in the mode field on the screen.
Machine
Channel reset
Program aborted
Jog
MCS Position
+ X 900.000 mm 0.000
- Y -156.000 mm 0.000
+ Z 230.000 mm 0.000
Auxiliary Functions
M0
M0
M0
H0.000000
H0.000000
H0.000000
M0
M0
+ X 900.000 mm
- Y -156.000 mm
+ Z 230.000 mm
Feedrate mm/min
Act. 3000.000 0.0 %
Set. 3000.000
Au t o
MDI
JOG
REPOS
REF
Tool
T0 D0
T0 D0
T0 D0
G1
.
.
.
1
Machine Parameters Program Services Diagnosis Start-up
1 = operating mode
Jog
MDI
Auto
To select the modes:
· JOG
· MDI
· Automatic
press one of the keys shown on the left on the machine control panel
or
the corresponding vertical softkey that you can access via the "Area
switchover" key:
JOG
· JOG
MDI
· MDI
AUTO
· Automatic
When a mode is selected, the LED next to the selection key on the
MCP lights up. The same status is signaled in the mode field on the
screen.

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
