5
"Parameters" Operating Area 03.04
5.3 Tool mana
ement
5
Ó Siemens AG, 2004. All rights reserved
5-216 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
5.3.7 Relocation
Function
This function allows you to move a selected tool from one location to
another.
Operating sequence
Tool ma-
nagement
Select softkey "Tool management".
The "Magazine list" is displayed.
The horizontal and vertical softkey bars change.
You can relocate a tool from the magazine list or the tool list. The
sequence of operations is the same for both methods.
Select the appropriate list via softkey:
Magazine
list
· "Magazine list"
Select the magazine and the tool to be relocated (position the
cursor on the magazine location containing the tool).
or
Tool list
· "Tool list"
Select the tool to be relocated
(position the cursor on the tool).
A tool must already have been loaded
(entry in the magazine number and location number columns).
Relocate
When you select the "Relocate" key, the "Relocate tool" window
opens.
There are 2 methods by which you can select the new location for the
tool:
· Enter the magazine and location numbers in the "Relocate tool"
window.
or
· Select softkey "Find empty location" and select the desired data in
the window.
