Siemens SINUMERIK 840D Operator's Guide

1
Introduction 03.04
1.1 The SINUMERIK 840D/810D s
y
stem
1
Ó Siemens AG, 2004. All rights reserved
1-22 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
1.1 The SINUMERIK 840D/810D system
General SINUMERIK 840D, 810D is a CNC control system (Computerized
Numerical Control) for machine tools.
You can implement the following basic functions (for a machine tool)
via the operator panel front of the CNC control:
· Create and adapt part programs,
· Execute part programs
· Manual control,
· Read in/out part programs and data,
· Edit data for programs,
· Display and troubleshoot alarms,
· Edit machine data,
· Set up communication links between 1 or more control units
(m) or 1 or more NCs (n)
(m:n, m control units and n NCK/PLC units).

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
