5
03.04 "Parameters" Operating Area
5.5 Settin
data
5
Ó Siemens AG, 2004. All rights reserved
SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition 5-241
5.5.8 Electronic gears (SW 6.3 and higher)
Function
The "electronic gear" function allows you to move a drive axis as a
following axis in synchronism with up to five leading axes. The
electronic gear is encoded via the following axis and has several lead
axes, each of which applies a gear ratio. The ratio to the drive axis
has a linear response and is defined as a coupling factor, numerator
to denominator. A gear group is defined and activated during part
program execution.
For further information, please see /PGA/, Programming Guide,
Advanced.
Operating sequence
Setting
data
Select softkey "Setting data".
The vertical softkey bar changes.
Further
>>>
Press the "Further" softkey.
Two further softkeys appear, "Gearbox link" and "<<" for changing to
the first softkey menu.
Gearbox
link
The vertical softkey menu changes to the "Electronic gear"
Following axis
Coupling factor Synchronization position
Leading axes Numerator Denominator Following axis Leading axis
· 1
:
Displays the position at which the teeth
· 2
:
of the electronically simulated gear
· 3
:
engage
· 4
:
· 5
:
Following
axis + +
Following
axis - -
You can use the softkeys "Following axis + +" and "Following axis - -"
to advance the following axis in both directions through the configured
gear stages. The motion component of the following axis is derived
from the coupling factors of the individual leading axes.
