Siemens SINUMERIK 840D Operator's Guide

4
Machine Operating Area 03.04
4.4 JOG mode
4
Ó Siemens AG, 2004. All rights reserved
4-134 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Other Information
As of SW 6.2:
Set zero point corresponds to $P_SETFR
Ext. WO frame corresponds to $P_EXTFR
Toolholder corresponds to $P_PARTFR)
Tool reference corresponds to $P_TOOLFR)
As of SW 6.3:
Workpiece reference corresponds to $P_WPFR)
Cycles corresponds to $P_CYCFR)
See also the figure at the end of 4.4.6

Siemens SINUMERIK 840D Specifications

General

Series	SINUMERIK 840D
Axes	Up to 31
Channels	Up to 10
Operating System	Windows-based
Power Supply	24 V DC
Control Unit Type	CNC
Interface	Ethernet, PROFIBUS
Display	TFT color display
Interpolation	Spline
PLC	Integrated PLC
Data Storage	CompactFlash, USB
