4
Machine Operating Area 03.04
4.6 Automatic mode
4
Ó Siemens AG, 2004. All rights reserved
4-152 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Define search destination in program editor:
Search
position
The current selected program level is displayed.
Position the cursor bar on a destination block of your choice in the
part program.
Program
level +
or
Program
level -
You can toggle between program levels using these softkeys if
necessary.
Defining the search destination in the search pointer:
Search
pointer
Once the softkey "search pointer" has been pressed, a screen with
the program pointer is displayed.
It contains input fields for program name, search type (block
number, text, ...) and search destination (content). The cursor is
positioned in the input field for the "search type".
0
...
5
You must enter your selected search type for the search destination in
input field "Type".
Information about the available search types is displayed in the dialog
line.
The following search types can be entered:
Search type (= jump to ...) Value in search type field
End of program 0
Block number 1
Jump label 2
Any character string 3
Program name 4
Line number 5
Different search types can be specified for different program levels.
A
...
Z
You can enter your chosen search destination (according to search
type) in the "Search destination" field.
0
...
9
You can enter the corresponding number of program passes in the
"P" field (pass counter).
Preset search destination to last program interruption point:
Interrup.
point
The search pointer is assigned the data of the last program
interruption point.
