5
"Parameters" Operating Area 03.04
5.3 Tool mana
ement
5
Ó Siemens AG, 2004. All rights reserved
5-192 SINUMERIK 840D/840Di/810D Operator's Guide HMI Advanced (BAD) – 03.04 Edition
Tool catalog and tool
cabinet
The tool catalog contains only "ideal" tools.
"Ideal" tools are characterized by the relevant tool "master data" (i.e.
with ideal tool dimensions, no wear, etc.). An "ideal" tool is uniquely
defined by its "tool name".
The tool cabinet contains only "real" tools.
"Real" tools (i.e. real tool dimensions, with wear, etc.) are
characterized by the relevant tool "offset data". A "real" tool is
uniquely defined by its "tool name" and the associated "Duplo
number". It is the "Duplo number" that assigns actual data to a "real"
tool.
If a connection to a host computer exists, a message is automatically
output to this host computer when a tool is loaded (but not relocated),
unloaded or deleted, and the corresponding data block is transferred.
The data are then still available on the host computer even after the
tool has been deleted.
Machine manufacturer
Please refer to the information supplied by your machine
manufacturer to see which functions are included in your tool
management.
See /FBW/ Description of Functions Tool Management or
/FBS/ Description of Functions ShopMill
